3.7 Inch Human Machine Interface HMI Touch Screen Panel 65536 True Colors Support Modbus

Place of Origin CHINA
Brand Name Coolmay
Certification CE
Model Number MT6037H
Minimum Order Quantity 1 pcs
Price Negotiable
Packaging Details Packed with standard carton box
Delivery Time 3-8 working day
Payment Terms T/T, Western Union, MoneyGra
Supply Ability 100,000 Sets per month

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

Product Details
Display Size 73*56MM Contrast Ratioe 400:1
Cutout Size 72*72MM Backlight LED
High Light

Modbus Human Machine Interface


3.7 Inch Human Machine Interface


65536 Colors HMI Touch Screen Panel

Leave a Message
Product Description

3.7 Inch HMI Human Machine Interface Touch Screen Panel 65536 True Colors Support Modbus​


Product Description



Model MT6037H
Type  hmi touch screen
Weight 0.3kg
Dimension size 88*88*25mm
Touch type 4-wire resistive panel
Backlight time 60000h
Download port Mini Type B port download program
COM port 1 rs232, 1 rs485
Protocol Support MODBUS, free port and common PLC communication Protocol
Certification CE

CoolMay HMI programming software

Detailed info. refer to CoolMay HMI user manual, CoolMay HMI programming manual




Coolmay MT6037H 3.7 inch true color touch screen, two installation methods, can be used in many occasions such as machinery and smart home, with 232 / 485 port, optional network port, support Modbus protocol, and can communicate with a variety of PLC. Three kinds of appearance: black plastic panel with black shell, gold metal panel with white shell, silver metal panel with black shell.


Product features


ü High-precision,high-reliability resistive touch panel.

ü Supports various formats of static images and GIF animations.

ü Support all fonts WINDOWS provided.

ü 60,000 TFT true color display.

ü Support vertical display.

ü Support Ethernet port and audio.

ü Default Rs232/Rs485 port,support multiple protocols.

ü Support 18 languages.




The products will be under testing for 1-3 days and packed with carton box .





By courier, door to door

For samples, the package will be delivered by DHL/UPS/FedEx/EMS express. Usually it will take 3-7 days to your location.

Post service

If you are not hurry but need economical delivery, we can go with packet channel. The delivery time depends on your location.

Air shipping or by sea

If bulk order, the packages will be delivered by air shipping or by ship.


3.7 Inch Human Machine Interface HMI Touch Screen Panel 65536 True Colors Support Modbus 0

After-sales service


  • Your products will be 18-months warranty excluding artificial damage.
  • You would receive unlimited support via video, phone or email.
  • OEM/ODM is supported, MOQ is 200 sets. More modules or functions can be customized as per your requirements.

3.7 Inch Human Machine Interface HMI Touch Screen Panel 65536 True Colors Support Modbus 1

3.7 Inch Human Machine Interface HMI Touch Screen Panel 65536 True Colors Support Modbus 2



1) Are you a manufacturer or trade company?
We are manufacturer of PLC,HMI,HMI PLC combo and other industrial products for over 16 years, we have engineers for study & design
and workers for produce and operate etc, we could support you one-stop products and service.
2) Do you have a CE certificate?
Yes for the products we exported, we could offer the CE for your Customs.
3) How long about the delivery?
It depends on the order details, and usually, we could support the delivery within 2-7 working days after payment confirmed.
4) Payment terms:
We accept TT Bank Transfer, Paypal, Credit Card on Alibab, Western Union ect.
